Foxeer Reaper Infinity 7.2G 64CH FPV VTx｜FPV 圖傳發射器

Adjust the power level and frequency: If the Tramp Rx pin cable on VTx is connected with FC, then the button doesn't work.

Name	Reaper 7.2G 10W VTX
Input Voltage	9~36V
Output Voltage	5V
Channels	64CH
Power	1W/2.5W/5W/7.5W/10W
Pit	Double click to enter
Weight	50g
Mounting Hole	2 Groups/20*20mm M2 2.5mm depth
Size	66.53716.5mm
Connector	SMA
Cable Connector	GH1 .25 8P
Consumption	10V/4.7A & 20V/2.0A;10W
Package Include	1 x VTx, 1 x silicon cable

Band	CH1	CH2	CH3	CH4	CH5	CH6	CH7	CH8
Band A	6110	6130	6150	6170	6190	6210	6230	6250
Band B	6270	6290	6310	6330	6350	6370	6390	6410
Band E	6430	6450	6470	6490	6510	6530	6550	6570
Band F	6590	6610	6630	6650	6670	6690	6710	6730
Band R	6750	6770	6790	6810	6830	6850	6870	6890
Band P	6910	6930	6950	6970	6990	7010	7030	7050
Band H	7070	7090	7110	7130	7150	7170	7190	7120
Band U	6115	6265	6425	6585	6745	6905	7065	7185

Note:

If tramp cable is connected, button will not work, can not adjust frequency and power, controller will take over.
