GEPRC Vapor-X5 HD O4 Pro FPV Drone

GEPRC Vapor-X5 HD O4 Pro FPV Drone|FPV 穿越機

options: PNP / 訂金預購
$5,600.00
跳到商品資訊
GEPRC Vapor-X5 HD O4 Pro FPV Drone

GEPRC Vapor-X5 HD O4 Pro FPV Drone|FPV 穿越機

$5,600.00
規格
付款方式

商品價格與庫存以實際確認為準;如遇缺貨或價格異常,我們將主動聯絡並提供退款或取消訂單。

GEPRC Vapor-X5 HD O4 Pro FPV Drone|FPV 穿越機

GEPRC 官方FPV 穿越機,已依台灣顧客使用習慣整理名稱、分類與付款方式。下單前請確認規格、接頭、頻段、極化方向、電壓及相關法規需求。

Summary

The GEPRC team has redesigned the Vapor series for optimal compatibility with the DJI O4 Air Unit Pro VTX.

New aluminum lens components and shock-absorbing silicone reduce vibrations, while the sharp new side panels give it a bold, mech-inspired look. The DJI O4 Air Unit Pro’s larger CMOS sensor enhances image detail and sensitivity, and the GEPRC-tuned PID settings ensure a smooth and immersive flight experience.

Available in two models, Wide X and DC, to suit different flight needs.

Feature

DJI O4 Air Unit Pro features a larger CMOS sensor for improved image clarity and enhanced light sensitivity.

CNC aluminum lens housing for a durable, bold design.

GEPRC SPEEDX2 E-series motors for smooth, powerful performance.

Front lip design provides extra lens protection for confident flying.

Wider 5mm carbon fiber arms for increased durability and a sleek build.

Specifications

Model: Vapor-X5 O4 Pro

Frame:

GEP-Vapor-X5 O4 Pro frame

Wheelbase: 230 mm

Top Plate: 2.0 mm

Middle Plate: 2.0 mm

Bottom Plate: 2.5 mm

Arm Thickness: 5.0 mm

FC: GEP-F722-HD v2

MCU: STM32F722

Gyro: ICM42688-P(SPI)

Barometer: YES

OSD: Betaflight OSD w/AT7456E

ESC: TAKER H60_BLS 60A 4IN1 ESC

VTX:

DJI O4 Air Unit Pro

Camera: O4 Pro Camera

Antenna: O4 Pro original antenna

Connector: XT60

Optional GPS: GEP-M10 GPS

5-inch Motor: GEPRC

SPEEDX2 2207E 1960 KV

5-inch Propeller: GEMFAN 5136

Vapor-X5 O4 PNP Version Weight: 409g±5g

Receiver: PNP/GEPRC ELRS24/TBS Nano RX

Recommended Battery: 6S LiPo1300mAh – 1800mAh

Flight Time: 14-19min

Includes

1 x Vapor-X5 O4 Pro

2 x GEMFAN 5136

2 x Battery anti-slip pads

1 x Spare screw pack

1 x Vapor side panel

2 x M20*250mm battery straps

1 x L-shaped screwdriver 1.5mm

1 x L-shaped screwdriver 2.0mm

1 x GoPro mount

The spare screws include

6 x M3*10mm round head screws

6 x M3*8mm round head screws

2 x M3*6mm flat head screws

1 x M5*28mm thin head screw

1 x M5 flange nut

4 x M3 rivet nuts
