GEPRC SPEEDX2 2806.5 1350KV/1760KV Motor｜無刷馬達

GEPRC SPEEDX2 2806.5 1350KV/1760KV Motor｜無刷馬達

GEPRC 官方無刷馬達，已依台灣顧客使用習慣整理名稱、分類與付款方式。下單前請確認規格、接頭、頻段、極化方向、電壓及相關法規需求。

Summary

The SPEEDX2 2806.5 brushless motor is the second generation motor of GEPRC,featuring a new design elements and a lighter structure.

The SPEEDX2 2806.5 motor has good heat dissipation, light weight, enough power, good stability and is made of customized high-quality materials. With linear and delicate throttle control and excellent magnetic circuit design.SPEEDX2 2806.5 has a super smooth flying experience with superb power, high durability and crash resistance.

SPEEDX2 2806.5 motor is perfect for 6-7 inch long range and cinematic FPV.

We are pursuing lighter weight, more responsive, more efficient and more powerful brushless motors.

Features

1. Ultra-light weight, only 48.0g.

2. Excellent magnetic design, stable power output.

3. Strong power and prompt response speed.

4. Delicate and precise throttle control, smooth flight experience.

5. Good structural design with high strength shell and excellent heat dissipation efficiency.

6. New optimized design for 6-7 inch propellers, perfectly suitable for 6-7 inch long range FPV models.

Specification

Model:SPEEDX2 2806.5-1350KV

KV: 1350KV

Configuration: 12N14P

Magnet: N52H ARC

Stator Diameter: 28mm

Stator Length: 6.5mm

Shaft Diameter: Φ4.0mm

Dimension: Φ34.8mm*33.9mm

Lead wire size: 20#AWG 250mm

Idle current (10V) : 1.25A

No. of Cells (LiPo) : 4-6S

Max Continuous Power(W) (5S): 960

Max Current (5S) : 40A

Internal Resistance: 58mΩ

Mounting Holes: 19x19mm

Weight: 48.0g

Suitable for: 6-7″ Long Range Quadcopter

Model:SPEEDX2 2806.5-1760KV

KV: 1760KV

Configuration: 12N14P

Magnet: N52H ARC

Stator Diameter: 28mm

Stator Lenght: 6.5mm

Shaft Diameter: Φ4.0mm

Dimension: Φ34.8mm*33.9mm

Lead wire Size: 20#AWG 250mm

Idle Current(10V): 1.7A

No. of Cells (LiPo): 4-6S

Max Continuous Power(W) (5S): 1200

Max Current (5S)：50A

Internal Resistance: 47mΩ

Mounting Holes: 19x19mm

Weight: 48.0g

Suitable Quadcopter: 6-7″ Long Range Quadcopter

Include

1 x SPEEDX2 2806.5 Motor

5 x M3*8mm Screws

5 x M3*10mm Screws

1 x M5 Flange Nut
