GEPRC Momoda2 5.8G antenna｜FPV 天線
GEPRC 官方FPV 天線，已依台灣顧客使用習慣整理名稱、分類與付款方式。下單前請確認規格、接頭、頻段、極化方向、電壓及相關法規需求。
Summary
The GEPRC Momoda2 5.8G antenna adopts the latest radio frequency solution in the FPV industry, pairing PCB with FPC structure to enhance signal frequency consistency while minimizing signal transmission power loss. It offers two polarization options, RHCP and LHCP, within the 5.8GHz frequency band.
Features
The ingenious exterior design integrates a sleek metallic style, appealing to the eye.
The advanced radio frequency structure effectively minimizes transmission loss.
The connectors come in various lengths and styles to accommodate diverse application needs.
Every antenna undergoes testing with a spectrum analyzer to ensure compliance with SWR standards.
Specifications
Model： GEPRC Momoda2 5.8G antenna
Center Frequency： 5.65G
Bandwidth：5.3GHz～6GHz
Polarization: LHCP/RHCP
Gain: 2.45dbi
Axial Ratio：≤3
SWR: ≤1.43
Radiation Efficiency: 85%
Cross Polarization Suppression: -25dB
Length：120mm-170mm
Antenna Design: FPC+PCB
Antenna Weight: 3.8g-11.6g
Enclosure Material: ABS
Connector Types: SMA / RP-SMA / AngleMMCX / UFL
Includes
1*Momoda 5.8G antenna
