GEPRC MATEN 3.3G VRX with 3.3G Signal Alarmer｜FPV 圖傳設備

GEPRC MATEN 3.3G VRX with 3.3G Signal Alarmer｜FPV 圖傳設備

GEPRC 官方FPV 圖傳設備，已依台灣顧客使用習慣整理名稱、分類與付款方式。下單前請確認規格、接頭、頻段、極化方向、電壓及相關法規需求。

Specifications

Model: GEPRC MATEN 3.3G VRX with 3.3G Signal Alarmer

Dimension: 52.3×87.5×14.7mm

Frequency: 3083-3480MHz

Channels: 40CH

Input Voltage: DC12-36V(3-8S Battery)

Antenna Connector: SMA

Sensitivity: -98dBm

Modes: VRX Mode, SCAN Mode

Video Connector: 3.5mm coaxial

Power Input: DC3.5mm/1.35mm

Mounting Hole: 1/4″ threaded hole

Weight: 69g

Frequency Bands

A:3083，3114，3145，3176，3207，3238，3269，3300

B:3215，3235，3255，3275，3295，3315，3335，3355

C:3170，3190，3210，3230，3250，3270，3290，3310

D:3320，3345，3370，3395，3420，3445，3470，3495

E:3310，3330，3355，3380，3405，3430，3455，3480

Instructions

VRX Mode: Switch to SCAN mode,press the BAND button to cycle through frequency bands, and the CHAN button to change channels. Hold either button to activate auto-scan, which will lock onto the channel with the strongest signal.

SCAN Mode: Switch to SCAN mode to automatically scan all available channels. The strongest signal will be displayed, and a beeper will sound, increasing in speed as the signal strength increases.

Includes

1 x MATEN 3.3G VRX with 3.3G Signal Alarmer

1 x Power supply cable

1 x Video signal cable

1 x User manual
