GEPRC GR2306.5 1350KV / 1850KV / 2450KV Motors｜無刷馬達

GEPRC GR2306.5 1350KV / 1850KV / 2450KV Motors｜無刷馬達

GEPRC 官方無刷馬達，已依台灣顧客使用習慣整理名稱、分類與付款方式。下單前請確認規格、接頭、頻段、極化方向、電壓及相關法規需求。

Specifications:

Item name:GR2306.5 Motors

KV:1350KV / 1850KV / 2450KV (Optional)

Configuration:12N14P

Stator Diamter:23mm

Stator Length:6.5mm

Shaft Diameter:4mm(Hollow)

Motor (Dimension(Dia.*Len)): Φ28.2*29.2mm

Idle current(10)@10V(A):1.95

of Cells(Lipo):4~5S

Max Continuous (Power(W)15S):1000

Internal Resistance:38mΩ

Max Current(15S):49A

Effciency Current:(3-7A)>85%

Rotor: N52H arc magnets

Bearings:JAPAN ISC

Base casing: Al 7075

Wire AWG: 20AWG

Weight(g):31g (not include wire)

Package included:

1x GEPRC GR2306.5 Motor

1x GEPRC M5 Aluminum Lock Nut

4x M3x7 Button head screws

4x M3x8 Button head screws
