GEPRC 官方無刷馬達，已依台灣顧客使用習慣整理名稱、分類與付款方式。下單前請確認規格、接頭、頻段、極化方向、電壓及相關法規需求。

Overview:

GR1102 is mainly designed for Toothpick frame and Whoop frame,lightweight and efficiency, Precise dynamic balance.

Feature:

Ultra-lightweight design but still high efficiency

NSK bearing

The prefect match toothpick Frame and Whoop frame

Used 1.6inch 4blade or 2.5inch 2blade Props

9000/10000KV/11000 options, Can be used in different batteries and propellers

Specification:

Mode: GR1102

KV options: 9000KV/10000KV/11000KV

Configuration: 9N12P

Stator Diamter: 11mm

Stator Length:2mm

Hole Type: 3 hole or 4 Hole

Shaft Diameter: Φ1mm or Φ1.5mm (option)

Motor Dimension(Dia.*Len): 13.8mm*15mm

Weight: 3.2g

No.of Cells(Lipo): 1S-3S Lipo/LiHV

Included:

1x GEPRC GR1102 brushless motor
