GEPRC Crocodile Baby 4 HD Long Range FPV(New F722 AIO)|FPV 穿越機
GEPRC 官方FPV 穿越機,已依台灣顧客使用習慣整理名稱、分類與付款方式。下單前請確認規格、接頭、頻段、極化方向、電壓及相關法規需求。
Summary:
The most distinguished 4 inch Long Range quadcopter, With superb light-weight design frame and more than 28 Minutes flight time, GEPRC Crocodile Baby 4inch is launching right now, It was just a complete out-of-body experience. There are two versions now:DJI HD VTX,Analog VTX 5.8G 600MW version. Pilots can choose whichever based on their likings.
Crocodile Baby 4 inch is the lightest 4-inch Micro Long Range FPV at present.The minimum takeoff weight is within 250g,which conforms to FAA rules. If you are looking for a FPV that can fly around 30 minutes, Crocodile Baby 4 inch is powerful and flexible flight.it will satisfy all your needs.
Crocodile Baby 4 inch is the preferred choice for Micro Long Range flight.The High efficiency power system, New Produced GEPRC 1404 2750kv motor and Gemfan 4024 propeller,Using the latest GEP-20A-F4 AIO flight control system, and combine with DJI HD picture transmission system, It is very stable flight and providing a feeling of “easy control” that inspires confidence, especially among novice.In the hands of a skilled pilots, the Crocodile Baby can bring extreme awesome experience as well. Extensive testing ensures that frame and system hold up in any environment, It can work well and get better flight efficiency. If equipped with GEPRC Lion VTC6 3000mAh battery, flight time is more than 28 minutes.
Crocodile Baby 4 inch independently designed GPS module, added GPS function. When signal losing or VTX out of control,It can be start the rescue mode of betaflight (in emergency, The FPV fly back to the approximate position of the base, If the signal is get again,Be sure to operate the FPV to landing manually.) ,The Rescue mode won’t landing automatically.Crocodile baby integrates GEPRC Finder. If the FPV lost and disconnects the battery power, the beeper of GEPRC Finder will making the sound constantly.
Crocodile Baby 4 inch is assembled and debugged by GEPRC TEAM, Improved performance and the flight performance of the whole FPV always superior in Micro Long Range FPV flight.
Changelog:
January 10, 2023: Crocodile Baby 4 HD version changed from CADDX Polar camera to Runcam Link Wasp camera.
July 27, 2023: Crocodile Baby 4 HD changed from GEP-M8U GPS to GEP-M10 GPS.
Specifications:
Brand: GEPRC
Model: Crocodile Baby 4″ HD
Frame:
GEP-CB4
Wheelbase: 174mm
The thickness of the top plate: 1.5mm
The thickness of the bottom plate: 2.0mm
The thickness of the arms plate: 2.5mm
XT30 Connector
Flight Controller System
:
GEP-F7-35A
(
New AIO
)
MCU: STM32F722RET6
Gyro: 6-Axis
Type-C USB interface
OSD: BetaFlight OSD w/ AT7456E chip
Integrated LC Filter
Power input: 4S LiPo
VTX: Caddx Vista
Props: Gemfan 4024
Antenna:
GEPRC Momoda 5.8g Antenna Long Version LHCP
Motors:
GR1404 2750KV
GPS:
GEP-M10
Crocodile Baby 4″ HD Weight:242g (Include 4S 750mAh battery)
Receiver: PNP(with DJI Receiver) / Frsky R-XSR/TBS Nano RX
Motors & Batteries Recommended:
Motors:
GR1404 2750KV
Battery:4S 650mAh – 1300mAh Lipo or
4S Lion 3000mAh
Under 250g weight:
Include:
1x Crocodile Baby 4″ HD Quads
4x Gemfan 4024 Props(pairs)
2x The silicone pad
3x L-shaped screwdriver
1x Antenna protection tube
1x Spare front arms
1x Spare rear arms
2x 12*180mm battery strap
1x 15*200mm battery strap
If equipped with GEPRC Lion VTC6 3000mAh Battery,flight time is more than 28 minutes.
