GEP-GR2205_2300KV motor｜無刷馬達

GEP-GR2205_2300KV motor｜無刷馬達

GEPRC 官方無刷馬達，已依台灣顧客使用習慣整理名稱、分類與付款方式。下單前請確認規格、接頭、頻段、極化方向、電壓及相關法規需求。

Summary:

GEP-GR2205 2300kv Racer Edition Motor, We studied a lot of flying habits. Motor most of the accelerator will be in the range of 60-90%, So the power of the motor is very important, So we use magnetic N45SH label, SH model with high magnetic loss characteristics, can let the motor to ensure high-speed running off magnetic, protection of electric, magnetic. The appearance design of durable structure, very suitable for racing requirements. Freestyle flight effect also can output power be not of the common sort, make the plane landed at high speed, flexible.

Specifications

：

Model: GR2205

KV: 2300kv

Weight: Approx. 29g with wires

Wire AWG: 20AWG

Cable length: 70mm

Stator Diameter: 22mm

Stator Height: 5mm

Shaft Diameter: 3mm

Configuration: 12N14P

Motor Diameter: 28mm

Motor Height: 33mm

Prop Adapter Shaft Thread: M5

Input voltage: 3S-4S (12.6 – 16.8v)

KV2300 With DAL5045X3BN Max.thrust:1135g(4S 16.8V)

Features：

The best effect and the best thrust of the accelerator is about 70%.

Using N45SH magnet, both to ensure that the torque, not to lose magnetism

3.5 mm aluminum flange lock nut, very light

Japan NMB bearings to ensure excellent operation of the motor

M3 *6 mm YFS screw

High temperature line 180℃
